Commercial Polystyrene Doors by Cloplay | Norther Utah

Overview

Commercial Steel Sectional Doors

ENERGY SERIES

Polystyrene Insulated Commercial Steel Doors, R-values to 9.1

Clopay Energy Series overhead sectional doors provide durability, energy efficiency and multiple performance and design options. They feature polystyrene insulation which helps reduce heating and cooling costs with years of reliable service.

These commercial doors offer stucco or woodgrain embossed steel exterior skins with flush, minor ribbed, or raised panel section designs. Ideal applications include warehouses, loading docks and industrial and agricultural facilities.

Glass/Window Options:

24" x 8" (3150, 3200, 3220)

24" x 12" (3150, 3200, 3220)

FULL-VIEW* (3150, 3200, 3220)

19-1/2" x 12" (3154, 3155, 3211, 3213)

*Intellicore® polyurethane option available in models 3200 & 3220.

Note: Windows available in insulated or insulated tempered glass.

GLAZING MATERIAL OPTIONS (904/904U):

CLEAR GLASS

GRAY TINTED GLASS

BRONZE TINTED GLASS

MIRRORED GLASS*

OBSCURE GLASS

WHITE LAMINATE GLASS*

FROSTED GLASS OR ACRYLIC

CLEAR ACRYLIC

GRAY ACRYLIC

WHITE ACRYLIC

CLEAR POLYCARBONATE

BRONZE POLYCARBONATE

ALUMINUM PANEL COLOR MATCH

*Mirrored and laminate not available in 1/2″

Glass thickness available in 1/8″, 1/4″ and 1/2″. Tri-wall polycarbonate thickness available in 1/2″. Low-E available on insulated glass.

COLOR OPTIONS:

STANDARD WHITE

CHOCOLATE

ALMOND

DESERT TAN

SANDTONE

MOCHA BROWN*

CHARCOAL

BRONZE

BLACK

COMMERCIAL

GRAY*

TRINAR® WHITE

TRINAR® BEIGE*

Request Color Samples

* Available on select models. For more information regarding color availability, click here.

Performance Options Available:

*Models 904U, 905U and 906U are not available with powder coat finish.

Performance Options Available:

Double-end hinge

3” Track

High performance hardware features 10 gauge end hinges, heavy-duty top bracket and 3″ sealed roller with 5/8″ stem.

Designed to counterbalance even the largest doors, commercial torsion spring assemblies can be designed for industry standard 10,000 cycles or can be upgraded to 25,000, 50,000 or 100,000 expected life cycles. Click here for details.

WindCode® reinforcement available up to W8 design pressure (DP) 52 PSF, depending on door configuration. Doors tested 50% greater than DP.

Upgrade your standard door with industrial-grade components.

Specialty Options Available:

Mullions

Carry-away, roll-away or swing-up mullions are
available on select sizes.

Break-Away Section

Single section and double sections available on select sizes.

Pass Door

32″ wide x 80″ high, max 16’2″ wide section. Available in 2″ thick doors only.

Safe-T-Stop™ Chain Hoist

The Safe-T-Stop is a controlled descent sectional door hand hoist with an integral braking system allowing users to operate the door with confidence.

Construction

ENERGY SERIES

Model	Section Thickness	Emboss	Ext. Skin Pattern	Ext. Steel Gauge	R-Value*	Thermal Break	Max Width	Max Height
3220	2″	Stucco	Flush	20 gauge	9.1	Thermally broken	26’2″	20’0″
3213	2″	Woodgrain	Raised panel	24 gauge	9.1	Thermally broken	24’2″	18’0″
3211	2″	Woodgrain	Flush	24 gauge	9.1	Thermally broken	24’2″	18’0″
3200	2″	Stucco	Minor Ribbed	24 gauge	9.1	Thermally broken	26’2″	20’0″
3155	1-3/8″	Woodgrain	Flush panel	27 gauge	6.5	Thermally broken	16’0″	16’0″
3154	1-3/8″	Woodgrain	Raised panel	27 gauge	6.5	Thermally broken	16’0″	16’0″
3150	1-3/8″	Stucco	Minor Ribbed	27 gauge	6.5	Thermally broken	16’0″	16’0″

*Calculated door section R-value is in accordance with DASMA TDS-163
